Hinged Joint 5/51/30 200m Apron Roll
Choose the picket height and finish for your job. These are individual pickets, not packs. The quantity is a planning starting point, not confirmation that a picket suits your fence, ground or loads.
Plan the whole fence · Browse singles and packs · Ask for a whole-job quote
- 2.50mm wire throughout — heavier than standard hardware mesh
- 260g/m² heavy galvanised coating
| Wire | 2.50mm throughout — horizontals HT, verticals MT |
| Coating | 260g/m² heavy galvanised |
Not sure how much you need? Run your fence through the calculator →
Hinged Joint 5/51/30
200m Apron Roll
Made in-house in Orange, NSW, with 2.5mm galvanised wire throughout.
Made for your fencing project
The Outback 5/51/30 roll has 5 horizontal line wires, a 51cm mesh height and 30cm spacing between vertical wires. Each roll supplies 200 metres of mesh before allowances for joins and your fence layout.
This 51cm mesh is intended as an apron or skirt alongside a suitable fence, rather than as a complete upright boundary fence.
2.5mm wire
High-tensile horizontal line wires and medium-tensile vertical wires, all 2.5mm.
Hinged joints
The wrapped hinge connections allow the mesh to flex as part of a correctly installed fence.
Galvanised steel
Galvanised wire for outdoor rural fencing. 30cm pocket spacing provides a wider pattern of vertical wires.
Specifications
| Wire configuration | 5/51/30 |
|---|---|
| Roll length | 200m |
| Mesh height | 51cm (0.51m) |
| Horizontal line wires | 5 |
| Pocket / vertical wire spacing | 30cm |
| Wire diameter | 2.5mm throughout |
| Horizontal wires | High tensile |
| Vertical wires | Medium tensile |
| Material | Galvanised steel |
| Joint type | Hinged joint |
| Approximate roll weight | 57kg |
| Manufacturing | Made in-house in Orange, NSW |
Get a roll quantity and freight quote
Tell us your fence length, roll quantity and delivery postcode. Our team can confirm current pricing, order quantities, production timing and freight.
Request a quoteCall 0434 093 077.
