Wet country or a long-life boundary? Hot-dip galvanised outlasts bitumen — only a couple of dollars more per picket.
Made in production runs, not warehoused. Current dispatch ~6 weeks — orders ship in the order they land, so locking yours in now holds your spot and your price.
- 2.50mm wire throughout — heavier than standard hardware mesh
- 260g/m² heavy galvanised coating
- Made on our machine in Orange, NSW
| Wire | 2.50mm throughout — horizontals HT, verticals MT |
| Coating | 260g/m² heavy galvanised |
| Manufacture | The Beast — Orange, NSW (Australian Made) |
Not sure how much you need? Run your fence through the calculator →
Hinged Joint 8/90/30
500m Roll
Extra wire, extra strength. 500 metres of 8-wire hinged joint mesh — tighter horizontal spacing for improved stock control on large-scale fencing runs.
The 8/90/30 Hinged Joint Fence in 500m rolls steps up from the standard 7-wire with an additional horizontal line wire — tightening the gaps between horizontals and giving you a stronger, more rigid mesh face. At 500 metres per roll, it's built for contractors and large landholders who want maximum coverage with fewer joins. Every roll is manufactured in-house at our Orange, NSW facility using 2.5mm hot-dip galvanised wire with our signature tightly wrapped hinge joint knot. The 8-wire configuration is the go-to upgrade when you need better containment for mixed stock, higher pressure areas, or simply want a fence that stands firmer between posts.
More wire, more control
8-Wire Strength
An extra horizontal wire tightens the mesh face, increasing rigidity and reducing the chance of stock pushing through under pressure.
500m — Fewer Joins
Cover half a kilometre per roll. Drastically reduces join points across a fence line — saving time, materials, and potential weak spots.
Hot-Dip Galvanised
Full hot-dip galvanised coating on all wires for maximum rust and corrosion resistance — built to last in harsh Australian conditions.
Understanding the wire configuration
The naming convention tells you everything about the mesh at a glance. Here's what each number in 8/90/30 represents:
Technical details
| Specification | Detail |
|---|---|
| Wire Configuration | 8/90/30 |
| Roll Height | 0.9m (90cm) |
| Roll Length | 500m |
| Horizontal Wires | 8 |
| Vertical Wire Spacing | 30cm |
| Wire Thickness (All Wires) | 2.5mm |
| Material | Hot-Dip Galvanised Steel |
| Knot Type | Tightly Wrapped Hinge Joint |
| Manufacturing | Made In-House — Orange, NSW |
Common applications
Orange, NSW
Galvanised
Throughout
Business
Need a bulk quote?
Running kilometres of fence? Call Jess on 0434 093 077 for volume pricing on pallet quantities.
